Digital to Analog Audio Converter, 192kHz 24bit DAC Converter with & 3.5mm Headphone Jack, Bass Adjustment, Noise Elimination, Support PCM Audio Format

Specification:Item Type: DAC ConverterMaterial: MetalSupport Audio Format: PCMResolution (1KHZ): 94DBResponse Frequency: 20Hz-20KHz-0.2db-to-Noise Ratio (SNR): -100DBTotal Harmonic Distortion (THD + N): 10Hz-20KHz 0.25-0.065%Blocked Time: 0.577FsSampling Rate: 32-192 KHzBit Rate: 16-24 bitsHeadphone Output (Adjust the Bass to the Maximum): 3V Output (Adjust the Bass to the Maximum): 9VHeadphone Output Power (Adjust the Bass to the Maximum): (32Ω) 30mWHeadphone Output Impedance: 0.8Ω Output Impedance: 450ΩWorking Voltage: + 5VMaximum Voltage: + 6VMaximum Power Consumption: 75mAWorking Temperature Range: -10-70℃Storage Temperature Range: -60-150℃Working Humidity Range: 10-80%RH (non-condensing)Storage Humidity Range: 5-90%RH (non-condensing)packing list:1 x DAC Converter1 x User Manual1 Cable1 x For Toslink Cable1 x USB Data CableNotice:1. This DAC supports digital PCM audio format. Before using PLS, please set your digital audio equipment (such as TV, TV BOX or game console) to PCM or LPCM audio. It doesn't support for DTS AC3.2. PCM setting : device homepage‑system setting‑image and sound‑voice setting‑digital audio output‑PCM3. It is suitable for or for TV. If you want to connect them, please follow the steps below

• [PROFESSIONAL AUDIO AMPLIFIER CHIP] - The built-in professional audio amplifier chip provides powerful stereo and heavy bass effects for a sound field environment.
• [EASY TO USE] - Easily convert digital audio from coaxial or optical interfaces to analog stereo with and 3.5mm headphone jack outputs.
• [VOLUME ADJUSTMENT KNOB] - Directly drive headphones and adjust volume with the built-in volume adjustment knob.
• [NOISE ELIMINATION & AUTO MUTE] - Eliminates noise when no input is detected and automatically mutes non-audio .
• [WIDE COMPATIBILITY] - Supports a 192kHz 24bit sampling rate and has and 3.5mm audio output interfaces for connecting to power amplifiers and headphones.
